High-Precision Gas Mass Flow Meter Coriolis Digital Mass Temperature Flow Meter Can Measure Diesel Liquid Nitrogen

October 22, 2024

Description:

We can supply High-Precision Gas Mass Flow Meter Coriolis Digital Mass Temperature Flow Meter Can Measure Diesel Liquid Nitrogen

Technical Parameter

Specifications	Accuracy Level	Nominal Diameter	Working Pressure	Working Temperature
Specifications	Accuracy Level	Nominal Diameter	（ MPa ）	（ ℃ ）
DN1 Coriolis Flow Meter	Class 0.2	DN1	4	-20°~140
DN3 Coriolis Flow Meter	Class 0.2	DN3	4	-20°~140
DN6 Coriolis Flow Meter	Class 0.2	DN6	4	-20°~140
DN8 Coriolis Flow Meter	Class 0.2	DN8	4	-20°~140
DN10 Coriolis Flow Meter	Class 0.2	DN10	4	-20°~140
DN15 Coriolis Flow Meter	Class 0.2	DN15	4	-20°~140
DN20 Coriolis Flow Meter	Class 0.2	DN20	4	-20°~140
DN25 Coriolis Flow Meter	Class 0.2	DN25	4	-20°~140
DN32 Coriolis Flow Meter	Class 0.2	DN32	4	-20°~140
DN40 Coriolis Flow Meter	Class 0.2	DN40	4	-20°~140
DN50 Coriolis Flow Meter	Class 0.2	DN50	4	-20°~140
DN80 Coriolis Flow Meter	Class 0.2	DN80	4	-20°~140
DN100 Coriolis Flow Meter	Class 0.2	DN100	4	-20°~140
DN150 Coriolis Flow Meter	Class 0.2	DN150	4	-20°~140

Accuracy: +0.1~0.5%
Repeatability: ±0.1~0.25%
Density measurement range: 0.3~3g/cm3,
Accuracy: +0.002g/cm3
Operating temperature: -50~+200°C (standard), -200~+300°C
Ambient temperature: -20~+60°C or -40~+60°C
Measuring tube material: SS316L;
Housing Material: SS304
Nominal pressure: 4.0MPa (standard)
Explosion-proof: Exd(ia)ICT6Gb
