Self-Coupling Transformer QZB Series For Motor Starting

June 15, 2024

Description:

We can supply Self-Coupling Transformer QZB Series For Motor Starting at best price.

An autotransformer is a single-turn transformer, in which the primary and secondary sides are wound together with one winding, and its transformer ratio is fixed. Compared with the general transformer of the same capacity, the autotransformer is particularly economical, especially in the case of the transformation ratio close to 1, so it is used more in the high-power transmission transformer with similar voltage, and is widely used in the step-down starting box of asynchronous motor above 10 kilowatts.

Technical Parameter

Model	Control The Motor To Persuade The String Kw	Model	Control The Motor To Persuade The Stringkw
QZB-14	14KW	QZB-75	75 KW
QZB-17	17KW	QZB-115	115 KW
QZB-20	20 KW	QZB-135	135 KW
QZB-22	22 KW	QZB-190	190 KW
QZB-28	28 KW	QZB-225	225 KW
QZB-30	30 KW	QZB-260	260 KW
QZB-40	40 KW	QZB-300	300 KW
QZB-45	45 KW
QZB-55	55 KW

Shape And Installation Dimensions

Model	Installation dimensions		Mounting holes	Dimensions
Model	A	C	K×J	B	D	E
QZB-14KW	230	115	12×20	280	144	226
QZB-17KW	230	115	12×20	280	144	226
QZB-20KW	272	105	8×20	279	138	229
QZB-22KW	272	105	8×20	279	138	229
QZB-28KW	284	113	9×20	321	153	261
QZB-30KW	284	113	9×20	321	153	261
QZB-40KW
QZB-45KW
QZB-55KW	248	132	14	352	163	280
QZB-75KW	246	125	14	371	164	295
QZB-111KW	312	161	12×18	392	203	314
QZB-115KW	312	161	12×18	392	203	314
QZB-135KW	310	168	12×18	392	207	342

Features

There Are Oriented Silicon Steel Sheets
Wuhan Iron and Steel is selected for cold rolling, with oriented silicon steel sheet, which has the advantages of good heat dissipation coefficient, low core loss and good magnetization characteristics

Pure Copper Coils
Pure oxygen copper coil is used, coated with double-layer insulating paint, with ultra-low wire loss, not easy to oxidize, and long service life.
